Middle Atlantic- RLNK-915R

15A,9 OUTLET,IP CONTROLLED RACKMOUNT POWER

Manufacturer: Middle Atlantic
Category: Power Distribution
SKU: RLNK-915R
Availability: In Stock
MSRP: $795.00
PRODUCT HIGHLIGHTS
Select Series Rack Mount PDU with RackLink™ Series power management products shall be Middle Atlantic Products model # RLNK-915R. Select Series Rack Mount PDU with RackLink power products shall be 1.735"H x 17.36"W x 9.67"D. Select Series Rack Mount PDU with RackLink shall have a 15 amp power capacity. Select Series Rack Mount PDU with RackLink shall provide MOV surge and spike protection. Select Series Rack Mount PDU with RackLink shall provide 9 total outlets, 8 of which shall be individually controllable. Select Series Rack Mount PDU with RackLink shall provide sequencing. Select Series Rack Mount PDU with RackLink shall include a 9' power cord. Select Series Rack Mount PDU with RackLink shall monitor specific remote IP devices and services and shall automatically reboot an unresponsive network device and provide alerts via e-mail. Select Series Rack Mount PDU with RackLink shall allow local export of log files in CSV format, and shall allow log files to be extracted to 3rd party databases via IP. Select Series Rack Mount PDU with RackLink shall include an integrated web server for browser-based access and control. Select Series Rack Mount PDU with RackLink shall utilize an open-architecture serial communications protocol that is cloud compliant without being cloud dependent, and provide an API for seamless integration into any IP based architecture. Select Series Rack Mount PDU with RackLink shall be fully compliant with any control system or aggregator. Select Series Rack Mount PDU with RackLink shall be constructed of phosphate pre-treated steel with a black powdercoat finish. Select Series Rack Mount PDU with RackLink shall meet the EU RoHS Directive 2011/65/EU. Select Series Rack Mount PDU with RackLink shall be manufactured by an ISO 9001 and ISO 14001 registered company. Select Series Rack Mount PDU with RackLink shall be warrantied to be free from defects in materials and workmanship under normal use and conditions for a period of 3 years. Select Series Rack Mount PDU with RackLink shall be listed to UL standard 60950-1 in US and to CAN/CSA C22.2 #60950-1 in Canada and FCC Part 15, Class B.
  • Individual IP outlet control of up to 8 outlets (9 outlets total)
  • Control start-up or shut-down with remote sequencing
  • Easy set-up and control through RackLink user interface
  • Multiple IP autoping and recovery ensuring optimal system functionality
  • MOV surge and spike protection
  • Fast and easy commissioning
  • Automatic actions improve system reliability
  • Automatic notification of connection status
FROM THE MANUFACTURER
CompanyLogo - RLNK-915R
FourImageText - RLNK-915R

Designed specifically for AV professionals, RackLink™ Cloud provides an intuitive and centralized interface for device-level control. Seamlessly manage and monitor all your Select Series PDUs and unlock new levels of efficiency, control, customer satisfaction, and revenue streams.

FourImageText - RLNK-915R

The Select Series PDUs with RackLink plugin enable outlet power control and status monitoring within the Q-SYS environment. This offers a simple and cost-effective solution that provides intelligent control of power distribution at your fingertips.

FourImageText - RLNK-915R

Have the confidence that Crestron Certified Modules and Q-SYS Certified Plug-ins for RackLink enabled products are developed and backed by Control Concepts, the premier software developer for the AV industry.

ImageHighlight - RLNK-915R

Seamlessly connect and control your PDU with flexible options for local, remote, and cloud management. The Premium+ PDU offers multiple ways to connect and manage your system.

Comparative - RLNK-915RComparative - RLNK-915RComparative - RLNK-915RComparative - RLNK-915R
RLNK-415RRLNK-420RRLNK-915RRLNK-920R
Line VoltageNominal: 120VAC / Min: 80VAC / Max: 140VACNominal: 120VAC / Min: 80VAC / Max: 140VACNominal: 120VAC / Min: 80VAC / Max: 140VACNominal: 120VAC / Min: 80VAC / Max: 140VAC
Maximum Peak Load15A20A15A20A
Maximum Continuous Load12A16A12A16A
No Load Power DissipationLess Than 1W (Ethernet disconnected, all relays off)Less Than 1W (Ethernet disconnected, all relays off)Less Than 1W (Ethernet disconnected, all relays off)Less Than 1W (Ethernet disconnected, all relays off)
Peak Impulse Current (8/20uS Waveform)- 12,000 Amps, one time, 9,000 Amps, two times within 5 minutes - Maximum peak impulse current pulse as defined between line and neutral - Maximum multiple impulse current derated per spec- 12,000 Amps, one time, 9,000 Amps, two times within 5 minutes - Maximum peak impulse current pulse as defined between line and neutral - Maximum multiple impulse current derated per spec- 12,000 Amps, one time, 9,000 Amps, two times within 5 minutes - Maximum peak impulse current pulse as defined between line and neutral - Maximum multiple impulse current derated per spec- 12,000 Amps, one time, 9,000 Amps, two times within 5 minutes - Maximum peak impulse current pulse as defined between line and neutral - Maximum multiple impulse current derated per spec
Protection ModeLine to Neutral only; no ground contaminationLine to Neutral only; no ground contaminationLine to Neutral only; no ground contaminationLine to Neutral only; no ground contamination
Response TimeLess than 1 nanosecond Less than 1 nanosecond Less than 1 nanosecond Less than 1 nanosecond
Surge Energy Dissipation120 Joules (10/100 microseconds) 120 Joules (10/100 microseconds) 120 Joules (10/100 microseconds) 120 Joules (10/100 microseconds)
EMI/RF Suppression>20dB Calculated Line to Neutral - 100kHz to 1Mhz >20dB Calculated Line to Neutral - 100kHz to 1Mhz >20dB Calculated Line to Neutral - 100kHz to 1Mhz >20dB Calculated Line to Neutral - 100kHz to 1Mhz
SPECIFICATIONS
General Information
ManufacturerMiddle Atlantic Products, Inc
Manufacturer Part NumberRLNK-915R
Manufacturer Website Addresshttp://www.middleatlantic.com
Brand NameMiddle Atlantic Products
Product LineRackLink
Product SeriesSelect
Product ModelRLNK-915R
Product NameRackLink Select RLNK-915R 9-Outlet PDU
Product TypePDU
Technical Information
PDU TypeBasic
Input ReceptaclesNEMA 5-15P
Output Receptacles9 x AC Power
Protection TypeSurge Protection
Spike Protection
Power Description
Input Current15 A
Management
ManagementIntegrated Web Server
Interfaces/Ports
Network (RJ-45)Yes
Physical Characteristics
Mounting OrientationHorizontal
PlacementRack
Form FactorRack-mountable
Miscellaneous
Environmentally FriendlyYes
Environmental CertificationRoHS
EU RoHS
ISO 14001
Country of OriginUnited States
Warranty
Limited Warranty3 Year
